规格表
| Part Number & Colour 料号和颜色 | Description 型号 | Will fit these cables 适用线缆 | Panel Dimensions 适用面板 | ||||
| Black 黑色 | UL Type 线缆类型 | AWG/Conductors 线芯 | Approximate Size 大约线径（mm） | Hole Size 孔径（mm） | Prevent Rotation 扁方尺寸（mm） | Thickness 厚度（mm） | |
| 1143 | SR-5N-5 | SV & SVT | 18/2 | 6.3 | 12.7 | 11.4 | 1.6 |
| 18/3 | 6.5 | 12.7 - 13.1 | |||||
| HPD | 18/2 | 6.9 | 12.7 | ||||
| 16/2 | 7.4 | 12.7 - 13.1 | |||||
| SJ & SJT | 18/2 | 7.6 | 13.5 | ||||
| 1226 | SR-6P-5 | SJ, SJO & SJT | 18/2 | 7.6 | 15.9 | 14 | 3.2 |
| 1232 | SR-6P2-5 | SJ, SJO & SJT | 16/2 18/3 | 8.0 8.1 | 15.9 | 14 | 3.2 |
| SJ | 14/2 | 8.1 | |||||
| 16/2 | 8.2 | ||||||
| 1223 | SR-6N3-5 | SJ, SJO & SJT | 18/3 14/2 16/3 | 8.4 8.9 9.0 | 15.9 | 14 | 1.6 |
| 18/4 | 9.1 | ||||||
| 16/2 | 8.2 | ||||||
| 1220 | SR-6P3-5 | SJ, SJO & SJT | 18/3 14/2 16/3 | 8.4 8.9 9.0 | 15.9 | 14 | 3.2 |
| 18/4 | 9.1 | ||||||
| 1020 | SR-2P-5 | CLOCK, X & XT | 20/2 | 2.3 x 4.6 | 9.5 | 8.4 | 1.6 |
| SPT-2 | 18/2 | 2.8 x 5.3 | |||||
| 1080 | SR-3P-5 | SPT-1 | 18/2 | 3.0 x 5.6 | 11.1 | 9.9 | 1.6 |
| 1108 | SR 4N-5 | SPT - 1 | 18/3 | 3.0 x 7.6 | 12.7 | 11.8 | 1.6 |
| SPT - 2&HPN | 18/2 | 3.8 x 7.1 | |||||
| 16/2 | 4.1 x 7.6 | 12.7 - 13.1 | |||||
| 1229 | SR 6K-5 | HPN | 18/3 16/2 | 3.8 x 8.6 4.1 x 9.4 | 15.9 | 14.0 | 3.2 |
| SPT - 2 | 16/2 16/3 | 4.1 x 7.6 4.1 x 10.4 | |||||
